AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
SPRS717F –OCTOBER 2011–REVISED APRIL 2013
www.ti.com
10
10
9
McASP[x]_ACLKR/X (Falling Edge Polarity)
McASP[x]_AHCLKR/X (Rising Edge Polarity)
12
11
12
McASP[x]_ACLKR/X (CLKRP = CLKXP = 1)(A)
McASP[x]_ACLKR/X (CLKRP = CLKXP = 0)(B)
13
13
13
13
McASP[x]_AFSR/X (Bit Width, 0 Bit Delay)
McASP[x]_AFSR/X (Bit Width, 1 Bit Delay)
McASP[x]_AFSR/X (Bit Width, 2 Bit Delay)
McASP[x]_AFSR/X (Slot Width, 0 Bit Delay)
McASP[x]_AFSR/X (Slot Width, 1 Bit Delay)
McASP[x]_AFSR/X (Slot Width, 2 Bit Delay)
13
13
13
McASP[x]_AXR[x] (Data Out/Transmit)
14
15
A0 A1
A30 A31 B0 B1
B30 B31 C0 C1 C2 C3
C31
A. For CLKRP = CLKXP = 1, the McASP transmitter is configured for falling edge (to shift data out) and the McASP
receiver is configured for rising edge (to shift data in).
B. For CLKRP = CLKXP = 0, the McASP transmitter is configured for rising edge (to shift data out) and the McASP
receiver is configured for falling edge (to shift data in).
Figure 5-87. McASP Output Timing
