9. POWER: The voltage supply that powers the terminal’s IO buffers.
10. HYS: Indicates if the input buffer is with hysteresis.
11. BUFFER STRENGTH: Drive strength of the associated output buffer.
12. PULLUP OR PULLDOWN TYPE: Denotes the presence of an internal pullup or pulldown resistor.
Pullup and pulldown resistors can be enabled or disabled via software.
13. IO CELL: IO cell information.
Note: Configuring two terminals to the same input signal is not supported as it can yield unexpected
results. This can be easily prevented with the proper software configuration.
