ADS131M04-Q1
ZHCSOL7A –MARCH 2022 –REVISED AUGUST 2022
www.ti.com.cn
8.6.3 MODE Register (Address = 2h) [reset = 0510h]
The MODE register is shown in 图8-28 and described in 表8-16.
Return to the Summary Table.
图8-28. MODE Register
15
14
13
12
11
10
9
1
8
RESERVED
R/W-00b
REG_CRC_EN RX_CRC_EN
CRC_TYPE
R/W-0b
RESET
R/W-1b
WLENGTH[1:0]
R/W-01b
R/W-0b
5
R/W-0b
7
6
4
3
2
0
RESERVED
R/W-000b
TIMEOUT
R/W-1b
DRDY_SEL[1:0]
R/W-00b
DRDY_HiZ
R/W-0b
DRDY_FMT
R/W-0b
表8-16. MODE Register Field Descriptions
Bit
Field
Type
Reset
Description
15:14
RESERVED
R/W
00b
Reserved
Always write 00b
13
REG_CRC_EN
R/W
R/W
R/W
R/W
0b
0b
0b
1b
Register map CRC enable
0b = Register CRC disabled (default)
1b = Register CRC enabled
12
11
10
RX_CRC_EN
CRC_TYPE
RESET
SPI input CRC enable
0b = Disabled (default)
1b = Enabled
SPI input and output, register map CRC type
0b = 16-bit CCITT (default)
1b = 16-bit ANSI
Reset
Write 0b to clear this bit in the STATUS register
0b = No reset
1b = Reset occurred (default by definition)
9:8
WLENGTH[1:0]
R/W
01b
Data word length selection
00b = 16 bits
01b = 24 bits (default)
10b = 32 bits; LSB zero padding
11b = 32 bits; MSB sign extension
7:5
4
RESERVED
TIMEOUT
R/W
R/W
000b
1b
Reserved
Always write 000b
SPI Timeout enable
0b = Disabled
1b = Enabled (default)
