TSC80C31/80C51
** This value is based on the maximum allowable die temperature and
the thermal resistance of the package
Absolute Maximum Ratings*
Ambient Temperature Under Bias :
* Notice
A = Automotive . . . . . . . . . . . . . . . . . . . . . . . . . . . . –40°C to +125°C
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . –65°C to + 150°C
Voltage on VCC to VSS . . . . . . . . . . . . . . . . . . . . . . . . –0.5 V to + 7 V
Voltage on Any Pin to VSS . . . . . . . . . . . . . . . –0.5 V to VCC + 0.5 V
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 W**
Stresses above those listed under “ Absolute Maximum Ratings” may
cause permanent damage to the device. This is a stress rating only and
functional operation of the device at these or any other conditions above
those indicated in the operational sections of this specification is not
implied. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability.
DC Parameters
TA = –40°C + 125°C ; VSS = 0 V ; VCC = 5 V ± 10 % ; F = 0 to 40 MHz
Symbol
VIL
Parameter
Min
– 0.5
Typ (3)
Max
Unit
V
Test Conditions
Input Low Voltage
0.2 Vcc – 0.1
Vcc + 0.5
Vcc + 0.5
VIH
Input High Voltage (Except XTAL and RST)
Input High Voltage (for XTAL and RST)
Output Low Voltage (Port 1, 2 and 3) (4)
0.2 Vcc + 0.9
0.7 Vcc
V
VIH1
VOL
V
0.3
0.45
1.0
V
V
V
IOL = 100 µA
IOL = 1.6 mA (2)
IOL = 3.5 mA
VOL1 Output Low Voltage (Port 0, ALE, PSEN) (4)
0.3
0.45
1.0
V
V
V
IOL = 200 µA
IOL = 3.2 mA (2)
IOL = 7.0 mA
Vcc – 0.3
Vcc – 0.7
Vcc – 1.5
V
V
V
IOH = – 10 µA
IOH = – 30 µA
VOH
Output High Voltage Port 1, 2 and 3
IOH = – 60 µA
VCC = 5 V ± 10 %
Vcc – 0.3
Vcc – 0.7
Vcc – 1.5
V
V
V
IOH = – 200 µA
VOH1 Output High Voltage (Port 0, ALE, PSEN)
IOH = – 3.2 mA
IOH = – 7.0 mA
VCC = 5 V ± 10 %
IIL
ILI
Logical 0 Input Current (Ports 1, 2 and 3)
Input leakage Current
– 75
±10
– 750
75
µA Vin = 0.45 V
µA 0.45 < Vin < Vcc
µA Vin = 2.0 V
ITL
Logical 1 to 0 Transition Current (Ports 1, 2 and 3)
Power Down Current
IPD
RRST
CIO
ICC
5
µA Vcc = 2.0 V to 5.5 V (1)
KW
RST Pulldown Resistor
50
90
200
10
Capacitance of I/O Buffer
pF fc = 1 MHz, Ta = 25_C
Power Supply Current
Vcc = 5.5 V
Freq = 1 MHz Icc op
Icc idle
Freq = 6 MHz Icc op
0.7
0.5
4.2
1.4
1.8
1
9
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
Icc idle
3.5
Freq ≥ 12 MHz Icc op max = 0.9 Freq (MHz) + 5
Icc idle max = 0.3 Freq (MHz) + 1.7
Freq ≤ 20 MHz Icc op typ = 0.7 Freq (MHz)
Freq ≥ 20 MHz Icc op typ = 0.5 Freq (MHz) + 4
Freq ≤ 20 MHz Icc idle typ = 0.16 Freq (MHz) + 0.4
Freq ≥ 20 MHz Icc idle typ = 0.12 Freq (MHz) + 1.2
10
