3.3 ELECTRICAL SPECIFICATIONS
3.3.1 D.C. Electrical Characteristics
Typical Operating Circuit of section 4.2, VDD = 1.8 V, VDDIO = 1.8 V, TA=25°C, unless otherwise noted.
PARAMETER
CONDITIONS
SUPPLY VOLTAGES
MIN
TYP
MAX
UNITS
NOTES
VDD
1.71
1.71
1.8
1.8
3.45
3.45
V
V
2
2
VDDIO
SUPPLY CURRENTS
6-Axis Gyroscope + Accelerometer
Low-Noise Mode
3.1
440
2.9
mA
µA
1
1
1
3-Axis Accelerometer
3-Axis Gyroscope
mA
Accelerometer Low -Power Mode
(Gyroscope disabled)
100Hz ODR, 1x averaging
100Hz ODR, 1x averaging
50
µA
1
1
Gyroscope Low-Power Mode
(Accelerometer disabled)
1.40
mA
6-Axis Low-Power Mode (Gyroscope
Low-Power Mode; Accelerometer Low-
Noise Mode)
100Hz ODR, 1x averaging
At 25ºC
1.66
6
mA
µA
1
1
Full-Chip Sleep Mode
TEMPERATURE RANGE
Specified Temperature Range
Performance parameters are not applicable
beyond Specified Temperature Range
-40
+85
°C
1
Table 3. D.C. Electrical Characteristics
Notes:
1. Target spec. Subject to update.
2. Derived from validation or characterization of parts, not guaranteed in production.
