MQFL-28-05S
Output:
Current:
5.0 V
24 A
Technical Specification
See Fig. 15
See Fig. 16
iC
MQME
Filter
MQFL
Converter
VOUT
VSOURCE
10
µ
Ω
F,
ESR
1 µF
ceramic
100m
capacitor
capacitor
Figure 14: Test set-up diagram showing measurement points for Input
Figure 13: Output voltage response to step-change in input voltage (16V -
Terminal Ripple Current (Figure 15) and Output Voltage Ripple (Figure
16).
50V - 16V). Load cap: 10
cap. Ch 1: Vout (200mV/div). Ch 2: Vin (20V/div).
µF, 100 mΩ ESR tantalum cap and 1µF ceramic
Figure 15: Input terminal current ripple, i , at full rated output current
and nominal input voltage with SynQor MQ filter module (50 mA/div).
Bandwidth: 20MHz. See Figure 14.
Figure 16: Output voltage ripple, Vout, at nominal input voltage and
c
rated load current (20 mV/div). Load capacitance: 1
µF ceramic capac-
itor and 10 F tantalum capacitor. Bandwidth: 10 MHz. See Figure 14.
µ
Figure 17: Rise of output voltage after the removal of a short circuit
Figure 18: SYNC OUT vs. time, driving SYNC IN of a second SynQor
across the output terminals. Ch 1: Vout (1V/div). Ch 2: Iout (10A/div).
MQFL converter. Ch1: SYNC OUT: (1V/div).
Product # MQFL-28-05S
Phone 1-888-567-9596
www.synqor.com
Doc.# 005-2MQ050S Rev. C
1/21/08
Page 7
