TS5070 - TS5071
AMPLITUDE RESPONSE (continued)
Symbol
Parameter
Min.
-0.1
Typ.
Max.
0.1
Unit
dB
GRAT
Receive Gain Variation with Temperature
Measure Relative to GRA
VCC = 5V, VSS = -5V -17dBm < 0dBm0 < 8.1dBm
GRAV
GRAF
Receive Gain Variation with Supply
Measured Relative to GRA
VCC = 5V 5%, V = -5V 5%
-0.05
0.05
dB
±
±
SS
TA = 25°C, 0dBm 0 = 8.1 dBm
Receive Gain Variation with Frequency
Relative to 1015.625 Hz, (note 2)
DR0 or DR1 = 0 dBm0 Code
-17.3dBm < 0 dBm0 < 8.1dBm
f = 200Hz
f = 300Hz to 3000Hz
f = 3400Hz
-0.25
-0.15
-0.7
0.15
0.15
0
dB
dB
dB
dB
f = 4000Hz
-14
GR = 0dBm0 = 8.1dBm
DR0 = -4dBm0
Relative to 1015.625 (note 2)
f = 296.875 Hz
f = 1906.250Hz
f = 2812.500Hz
f = 2984.375Hz
f = 3406.250Hz
f = 3984.375Hz
-0.15
-0.15
-0.15
-0.15
-0.74
0.15
0.15
0.15
0.15
0
dB
dB
dB
dB
dB
dB
-13.5
GRAL
Receive Gain Variation with Signal Level
Sinusoidal Test Method Reference Level = 0dBm0
DR0 = -40dBm0 to +3dBm0
DR0 = -50dBm0 to -40dBm0
DR0 = -55dBm0 to -50dBm0
DR0 = 3.1dBm0
-0.2
-0.4
-1.2
0.2
0.4
1.2
dB
dB
dB
R = 600 , 0dBm0 = 7.6dBm
-0.2
-0.2
0.2
0.2
dB
dB
Ω
L
R = 300 , 0dBm0 = 6.9dBm
Ω
L
24/32
