Electrical characteristics
Symbol
STM8S903K3 STM8S903F3
Parameter
Min
Max
Unit
Conditions(1)
(3) (4)
ta(SO)
Data output
access time
Slave mode
3 x
tMASTER
(3) (5)
tdis(SO)
Data output
disable time
Slave mode
25
(3)
tv(SO)
Data output valid Slave mode
65(2)
30
time
(after enable edge)
(3)
tv(MO)
Data output valid Master mode
time
(after enable edge)
(3)
th(SO)
Data output hold Slave mode
27(2)
11(2)
time
(after enable edge)
(3)
th(MO)
Data output hold Master mode
time
(after enable edge)
(1) Parameters are given by selecting 10 MHz I/O output frequency.
(2) Data characterization in progress.
(3) Values based on design simulation and/or characterization results, and not tested in
production.
(4) Min time is for the minimum time to drive the output and the max time is for the maximum
time to validate the data.
(5) Min time is for the minimum time to invalidate the output and the max time is for the
maximum time to put the data in Hi-Z.
