Electrical characteristics

STM8S903K3 STM8S903F3

Figure 36: Typical NRST pull-up resistance vs V_DD@ 4 temperatures

Figure 37: Typical NRST pull-up current vs V_DD@ 4 temperatures

The reset network shown in the following figure protects the device against parasitic resets.

The user must ensure that the level on the NRST pin can go below V_IL(NRST)max. (see Table

40: I/O static characteristics ), otherwise the reset is not taken into account internally.

For power consumption sensitive applications, the external reset capacitor value can be

reduced to limit the charge/discharge current. If NRST signal is used to reset external circuitry,

attention must be taken to the charge/discharge time of the external capacitor to fulfill the

external devices reset timing conditions. Minimum recommended capacity is 100 nF.
