A d v a n c e I n f o r m a t i o n
Table 7. S29GL032A (Models R1, R2) Sector Addresses
Sector
Size
(KB/
Sector
Size
(KB/
8-bit
Address
Range
16-bit
Address
Range
8-bit
Address
Range
16-bit
Address
Range
Sector A20-A15
Sector A20-A15
Kwords)
Kwords)
SA0 0 0 0 0 0 0 64/32
SA1 0 0 0 0 0 1 64/32
SA2 0 0 0 0 1 0 64/32
SA3 0 0 0 0 1 1 64/32
SA4 0 0 0 1 0 0 64/32
SA5 0 0 0 1 0 1 64/32
SA6 0 0 0 1 1 0 64/32
SA7 0 0 0 1 1 1 64/32
SA8 0 0 1 0 0 0 64/32
SA9 0 0 1 0 0 1 64/32
SA10 0 0 1 0 1 0 64/32
SA11 0 0 1 0 1 1 64/32
SA12 0 0 1 1 0 0 64/32
SA13 0 0 1 1 0 1 64/32
SA14 0 0 1 1 1 0 64/32
SA15 0 0 1 1 1 1 64/32
SA16 0 1 0 0 0 0 64/32
SA17 0 1 0 0 0 1 64/32
SA18 0 1 0 0 1 0 64/32
SA19 0 1 0 0 1 1 64/32
SA20 0 1 0 1 0 0 64/32
SA21 0 1 0 1 0 1 64/32
SA22 0 1 0 1 1 0 64/32
SA23 0 1 0 1 1 1 64/32
SA24 0 1 1 0 0 0 64/32
SA25 0 1 1 0 0 1 64/32
SA26 0 1 1 0 1 0 64/32
SA27 0 1 1 0 1 1 64/32
SA28 0 1 1 1 0 0 64/32
SA29 0 1 1 1 0 1 64/32
SA30 0 1 1 1 1 0 64/32
SA31 0 1 1 1 1 1 64/32
000000–00FFFF
010000–01FFFF
020000–02FFFF
030000–03FFFF
040000–04FFFF
050000–05FFFF
060000–06FFFF
070000–07FFFF
080000–08FFFF
090000–09FFFF
0A0000–0AFFFF
0B0000–0BFFFF
0C0000–0CFFFF
0D0000–0DFFFF
0E0000–0EFFFF
0F0000–0FFFFF
100000–10FFFF
110000–11FFFF
120000–12FFFF
130000–13FFFF
140000–14FFFF
150000–15FFFF
160000–16FFFF
170000–17FFFF
180000–18FFFF
190000–19FFFF
1A0000–1AFFFF
1B0000–1BFFFF
1C0000–1CFFFF
1D0000–1DFFFF
1E0000–1EFFFF
1F0000–1FFFFF
000000–007FFF
008000–00FFFF
010000–017FFF
018000–01FFFF
020000–027FFF
028000–02FFFF
030000–037FFF
038000–03FFFF
040000–047FFF
048000–04FFFF
050000–057FFF
058000–05FFFF
060000–067FFF
068000–06FFFF
070000–077FFF
078000–07FFFF
080000–087FFF
088000–08FFFF
090000–097FFF
098000–09FFFF
0A0000–0A7FFF
0A8000–0AFFFF
0B0000–0B7FFF
0B8000–0BFFFF
0C0000–0C7FFF
0C8000–0CFFFF
0D0000–0D7FFF
0D8000–0DFFFF
0E0000–0E7FFF
0E8000–0EFFFF
0F0000–0F7FFF
0F8000–0FFFFF
SA32 1 0 0 0 0 0 64/32
SA33 1 0 0 0 0 1 64/32
SA34 1 0 0 0 1 0 64/32
SA35 1 0 0 0 1 1 64/32
SA36 1 0 0 1 0 0 64/32
SA37 1 0 0 1 0 1 64/32
SA38 1 0 0 1 1 0 64/32
SA39 1 0 0 1 1 1 64/32
SA40 1 0 1 0 0 0 64/32
SA41 1 0 1 0 0 1 64/32
SA42 1 0 1 0 1 0 64/32
SA43 1 0 1 0 1 1 64/32
SA44 1 0 1 1 0 0 64/32
SA45 1 0 1 1 0 1 64/32
SA46 1 0 1 1 1 0 64/32
SA47 1 0 1 1 1 1 64/32
SA48 1 1 0 0 0 0 64/32
SA49 1 1 0 0 0 1 64/32
SA50 1 1 0 0 1 0 64/32
SA51 1 1 0 0 1 1 64/32
SA52 1 1 0 1 0 0 64/32
SA53 1 1 0 1 0 1 64/32
SA54 1 1 0 1 1 0 64/32
SA55 1 1 0 1 1 1 64/32
SA56 1 1 1 0 0 0 64/32
SA57 1 1 1 0 0 1 64/32
SA58 1 1 1 0 1 0 64/32
SA59 1 1 1 0 1 1 64/32
SA60 1 1 1 1 0 0 64/32
SA61 1 1 1 1 0 1 64/32
SA62 1 1 1 1 1 0 64/32
SA63 1 1 1 1 1 1 64/32
200000–20FFFF
210000–21FFFF
220000–22FFFF
230000–23FFFF
240000–24FFFF
250000–25FFFF
260000–26FFFF
270000–27FFFF
280000–28FFFF
290000–29FFFF
2A0000–2AFFFF
2B0000–2BFFFF
2C0000–2CFFFF
2D0000–2DFFFF
2E0000–2EFFFF
2F0000–2FFFFF
300000–30FFFF
310000–31FFFF
320000–32FFFF
330000–33FFFF
340000–34FFFF
350000–35FFFF
360000–36FFFF
370000–37FFFF
380000–38FFFF
390000–39FFFF
3A0000–3AFFFF
3B0000–3BFFFF
3C0000–3CFFFF
3D0000–3DFFFF
3E0000–3EFFFF
3F0000–3FFFFF
100000–107FFF
108000–10FFFF
110000–117FFF
118000–11FFFF
120000–127FFF
128000–12FFFF
130000–137FFF
138000–13FFFF
140000–147FFF
148000–14FFFF
150000–157FFF
158000–15FFFF
160000–167FFF
168000–16FFFF
170000–177FFF
178000–17FFFF
180000–187FFF
188000–18FFFF
190000–197FFF
198000–19FFFF
1A0000–1A7FFF
1A8000–1AFFFF
1B0000–1B7FFF
1B8000–1BFFFF
1C0000–1C7FFF
1C8000–1CFFFF
1D0000–1D7FFF
1D8000–1DFFFF
1E0000–1E7FFF
1E8000–1EFFFF
1F0000–1F7FFF
1F8000–1FFFFF
April 22, 2005 S29GL-A_00_A3
S29GL-A MirrorBit™ Flash Family
23
