A d v a n c e I n f o r m a t i o n
Table 3. S29GL064A Valid Combinations
S29GL064A Valid Combinations
Package, Material &
Package Description
Device Number Speed Option
Model Number
Packing Type
Temperature Range
R3, R4, R6, R7, R8, R9
R1, R2
TS048 (Note 2)
TS056 (Note 2)
TSOP
TSOP
TAI, TFI
0, 2, 3
(Note 1)
S29GL064A
90, 10, 11
BAI, BFI
FAI, FFI
R3, R4, R5
VBN048 (Note 3) Fine-pitch BGA
LAA064 (Note 3) Fortified BGA
R1, R2, R3, R4, R5
Notes:
1. Type 0 is standard. Specify others as required: TSOPs can be packed in Types 0 and 3; BGAs can be packed in Types 0, 2, or 3.
2. TSOP package marking omits packing type designator from ordering part number.
3. BGA package marking omits leading S29 and packing type designator from ordering part number.
Valid Combinations
Valid Combinations list configurations planned to be supported in volume for this
device. Consult your local sales office to confirm availability of specific valid com-
binations and to check on newly released combinations.
April 22, 2005 S29GL-A_00_A3
S29GL-A MirrorBit™ Flash Family
17
