BUFFER
NAME
SYMBOL
TYPE
DESCRIPTION
SD Command
SD_CMD
I/O8PU
This is a bi-directional signal that connects to the CMD
signal of SD/MMC device.
This pin has an internally controlled weak pull-up
resistor.
SD
SD_nWP
IPD
This pin is an input signal with an internal weak pull-
down.
Write Protected
This pin has an internally controlled weak pull-down
resistor.
MISC
General Purpose
I/O
GPIO1
GPIO2
GPIO4
GPIO5
GPIO6
I/O8
I/O8
I/O8
I/O8
IPU
This pin may be used either as input, edge sensitive
interrupt input, or output.
General Purpose
I/O
This pin may be used either as input, edge sensitive
interrupt input, or output.
General Purpose
I/O
This pin may be used either as input, edge sensitive
interrupt input, or output.
General Purpose
I/O
This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO6
This pin has an internal weak pull-up resistor that is
enabled or disabled by the state of RESET_N.
The pull-up is enabled when RESET_N is active.
The pull-up is disabled, when the RESET_N is inactive
(some clock cycles later, after the rising edge of
RESET_N).
The state of this pin is latched internally on the rising
edge of RESET_N to determine if internal or external
program memory is used.
The state latched is stored in ROMEN bit of GPIO_IN1
register.
I/O8
After the rising edge of RESET_N, this pin may be used
as GPIO6.
When this pin is left unconnected or pulled high by a
weak pull-up resistor, the USB2601/USB2602 uses the
internal ROM for program execution.
This pin may be used either as input, edge sensitive
interrupt input, or output.
General Purpose
I/O
GPIO7
I/O8
I/O8
This pin may be used either as input, edge sensitive
interrupt input, or output.
General Purpose
GPIO8/
GPIO: This pin may be used either as input, edge
sensitive interrupt input, or output.
I/O
Or
CRD_PWR0
CRD_PWR: Card Power drive of 3.3V @ 100mA.
Card Power
General Purpose
I/O
GPIO9
I/O8
I/O8
This pin may be used either as input, edge sensitive
interrupt input, or output.
General Purpose
GPIO10/
GPIO: This pin may be used either as input, edge
sensitive interrupt input, or output.
I/O
Or
CRD_PWR1
CRD_PWR: Card Power drive of 3.3V @ 100mA.
Card Power
