Advanced I/O Controller with Motherboard GLUE Logic
Datasheet
Table 6.32 - Register Summary for an Individual UART Channel
REGISTER
ADDRESS*
REGISTER
SYMBOL
REGISTER NAME
BIT 0
BIT 1
ADDR = 0
DLAB = 0
ADDR = 0
DLAB = 0
ADDR = 1
DLAB = 0
Receive Buffer Register (Read Only)
RBR
THR
IER
Data Bit 0
Data Bit 1
(Note 1)
Transmitter Holding Register (Write
Only)
Interrupt Enable Register
Data Bit 0
Data Bit 1
Enable
Enable
Received
Data
Transmitter
Holding
Available
Interrupt
(ERDAI)
Register
Empty
Interrupt
(ETHREI)
ADDR = 2
Interrupt Ident. Register (Read Only)
IIR
“0” if
Interrupt ID
Interrupt
Pending
Bit
ADDR = 2
ADDR = 3
FIFO Control Register (Write Only)
Line Control Register
FCR
FIFO
RCVR FIFO
Reset
(Note 7)
Enable
LCR
Word
Word
Length
Length
Select Bit 0 Select Bit 1
(WLS0)
(WLS1)
ADDR = 4
MODEM Control Register
MCR
Data
Request to
Send (RTS)
Terminal
Ready
(DTR)
ADDR = 5
ADDR = 6
Line Status Register
LSR
Data Ready Overrun
(DR) Error (OE)
MODEM Status Register
MSR
Delta Clear Delta Data
to Send
(DCTS)
Set Ready
(DDSR)
ADDR = 7
ADDR = 0
DLAB = 1
ADDR = 1
DLAB = 1
Scratch Register (Note 4)
Divisor Latch (LS)
SCR
DDL
Bit 0
Bit 0
Bit 1
Bit 1
Divisor Latch (MS)
DLM
Bit 8
Bit 9
*DLAB is Bit 7 of the Line Control Register (ADDR = 3).
Note 1: Bit 0 is the least significant bit. It is the first bit serially transmitted or received.
Note 2: When operating in the XT mode, this bit will be set any time that the transmitter shift register is empty.
SMSC LPC47M182
91
Revision 1.8 SMSC/Non-SMSC Register Sets (02-24-05)
