Three Port 10/100 Managed Ethernet Switch with MII
Datasheet
Table 13.1 System Control and Status Registers (continued)
ADDRESS
OFFSET
SYMBOL
REGISTER NAME
1588_SEQ_ID_SRC_UUID_HI_TX_CAPTURE_MII
158h
15Ch
160h
164h
168h
16Ch
Port 0 1588 Sequence ID, Source UUID High-WORD
Transmit Capture Register, Section 13.1.4.7
1588_SRC_UUID_LO_TX_CAPTURE_MII
1588_CLOCK_HI_CAPTURE_GPIO_8
1588_CLOCK_LO_CAPTURE_GPIO_8
1588_CLOCK_HI_CAPTURE_GPIO_9
1588_CLOCK_LO_CAPTURE_GPIO_9
Port 0 1588 Source UUID Low-DWORD Transmit Capture
Register, Section 13.1.4.8
GPIO 8 1588 Clock High-DWORD Capture Register,
Section 13.1.4.9
GPIO 8 1588 Clock Low-DWORD Capture Register,
Section 13.1.4.10
GPIO 9 1588 Clock High-DWORD Capture Register,
Section 13.1.4.11
GPIO 9 1588 Clock Low-DWORD Capture Register,
Section 13.1.4.12
1588_CLOCK_HI
1588_CLOCK_LO
170h
174h
178h
17Ch
1588 Clock High-DWORD Register, Section 13.1.4.13
1588 Clock Low-DWORD Register, Section 13.1.4.14
1588 Clock Addend Register, Section 13.1.4.15
1588_CLOCK_ADDEND
1588_CLOCK_TARGET_HI
1588 Clock Target High-DWORD Register,
Section 13.1.4.16
1588_CLOCK_TARGET_LO
1588_CLOCK_TARGET_RELOAD_HI
1588_CLOCK_TARGET_RELOAD_LO
1588_AUX_MAC_HI
180h
184h
188h
18Ch
190h
1588 Clock Target Low-DWORD Register,
Section 13.1.4.17
1588 Clock Target Reload High-DWORD Register,
Section 13.1.4.18
1588 Clock Target Reload/Add Low-DWORD Register,
Section 13.1.4.19
1588 Auxiliary MAC Address High-WORD Register,
Section 13.1.4.20
1588_AUX_MAC_LO
1588 Auxiliary MAC Address Low-DWORD Register,
Section 13.1.4.21
1588_CONFIG
1588_INT_STS_EN
1588_CMD
194h
198h
19Ch
1A0h
1A4h
1A8h
1ACh
1588 Configuration Register, Section 13.1.4.22
1588 Interrupt Status Enable Register, Section 13.1.4.23
1588 Command Register, Section 13.1.4.24
MANUAL_FC_1
MANUAL_FC_2
MANUAL_FC_MII
SWITCH_CSR_DATA
Port 1 Manual Flow Control Register, Section 13.1.5.1
Port 2 Manual Flow Control Register, Section 13.1.5.2
Port 0 Flow Control Register, Section 13.1.5.3
Switch Fabric CSR Interface Data Register,
Section 13.1.5.4
SWITCH_CSR_CMD
1B0h
Switch Fabric CSR Interface Command Register,
Section 13.1.5.5
E2P_CMD
E2P_DATA
1B4h
1B8h
1BCh
1C0h
1C4h
EEPROM Command Register, Section 13.1.3.1
EEPROM Data Register, Section 13.1.3.2
LED_CFG
LED Configuration Register, Section 13.1.2.4
Virtual PHY Basic Control Register, Section 13.1.7.1
Virtual PHY Basic Status Register, Section 13.1.7.2
VPHY_BASIC_CTRL
VPHY_BASIC_STATUS
SMSC LAN9313/LAN9313i
149
Revision 1.2 (04-08-08)
DATASHEET
