Three Port 10/100 Managed Ethernet Switch with MII
Datasheet
Table 13.1 System Control and Status Registers (continued)
ADDRESS
OFFSET
SYMBOL
REGISTER NAME
Reserved for Future Use
RESERVED
0ACh - 0FCh
100h
1588_CLOCK_HI_RX_CAPTURE_1
Port 1 1588 Clock High-DWORD Receive Capture
Register, Section 13.1.4.1
1588_CLOCK_LO_RX_CAPTURE_1
1588_SEQ_ID_SRC_UUID_HI_RX_CAPTURE_1
1588_SRC_UUID_LO_RX_CAPTURE_1
1588_CLOCK_HI_TX_CAPTURE_1
104h
108h
10Ch
110h
114h
118h
11C
Port 1 1588 Clock Low-DWORD Receive Capture Register,
Section 13.1.4.2
Port 1 1588 Sequence ID, Source UUID High-WORD
Receive Capture Register, Section 13.1.4.3
Port 1 1588 Source UUID Low-DWORD Receive Capture
Register, Section 13.1.4.4
Port 1 1588 Clock High-DWORD Transmit Capture
Register, Section 13.1.4.5
1588_CLOCK_LO_TX_CAPTURE_1
Port 1 1588 Clock Low-DWORD Transmit Capture
Register, Section 13.1.4.6
1588_SEQ_ID_SRC_UUID_HI_TX_CAPTURE_1
1588_SRC_UUID_LO_TX_CAPTURE_1
1588_CLOCK_HI_RX_CAPTURE_2
Port 1 1588 Sequence ID, Source UUID High-WORD
Transmit Capture Register, Section 13.1.4.7
Port 1 1588 Source UUID Low-DWORD Transmit Capture
Register, Section 13.1.4.8
120h
124h
128h
12Ch
130h
134h
138h
13Ch
140h
144h
148h
14Ch
150h
154h
Port 2 1588 Clock High-DWORD Receive Capture
Register, Section 13.1.4.1
1588_CLOCK_LO_RX_CAPTURE_2
Port 2 1588 Clock Low-DWORD Receive Capture Register,
Section 13.1.4.2
1588_SEQ_ID_SRC_UUID_HI_RX_CAPTURE_2
1588_SRC_UUID_LO_RX_CAPTURE_2
1588_CLOCK_HI_TX_CAPTURE_2
Port 2 1588 Sequence ID, Source UUID High-WORD
Receive Capture Register, Section 13.1.4.3
Port 2 1588 Source UUID Low-DWORD Receive Capture
Register, Section 13.1.4.4
Port 2 1588 Clock High-DWORD Transmit Capture
Register, Section 13.1.4.5
1588_CLOCK_LO_TX_CAPTURE_2
Port 2 1588 Clock Low-DWORD Transmit Capture
Register, Section 13.1.4.6
1588_SEQ_ID_SRC_UUID_HI_TX_CAPTURE_2
1588_SRC_UUID_LO_TX_CAPTURE_2
1588_CLOCK_HI_RX_CAPTURE_MII
1588_CLOCK_LO_RX_CAPTURE_MII
1588_SEQ_ID_SRC_UUID_HI_RX_CAPTURE_MII
1588_SRC_UUID_LO_RX_CAPTURE_MII
1588_CLOCK_HI_TX_CAPTURE_MII
1588_CLOCK_LO_TX_CAPTURE_MII
Port 2 1588 Sequence ID, Source UUID High-WORD
Transmit Capture Register, Section 13.1.4.7
Port 2 1588 Source UUID Low-DWORD Transmit Capture
Register, Section 13.1.4.8
Port 0 1588 Clock High-DWORD Receive Capture
Register, Section 13.1.4.1
Port 0 1588 Clock Low-DWORD Receive Capture Register,
Section 13.1.4.2
Port 0 1588 Sequence ID, Source UUID High-WORD
Receive Capture Register, Section 13.1.4.3
Port 0 1588 Source UUID Low-DWORD Receive Capture
Register, Section 13.1.4.4
Port 0 1588 Clock High-DWORD Transmit Capture
Register, Section 13.1.4.5
Port 0 1588 Clock Low-DWORD Transmit Capture
Register, Section 13.1.4.6
Revision 1.2 (04-08-08)
148
SMSC LAN9313/LAN9313i
DATASHEET
