Table 6.6 RX Data FIFO Direct PIO Burst Read Cycle Timing
SYMBOL
DESCRIPTION
MIN
TYP
MAX
UNITS
tdoff
tdoh
Data Buffer Turn Off Time
Data Output Hold Time
7
ns
ns
0
Note: An RX Data FIFO Direct PIO Burst Read cycle begins when both nCS and nRD are asserted.
The cycle ends when either or both nCS and nRD are deasserted. They may be asserted and
deasserted in any order.
6.6
PIO Writes
PIO writes are used for all LAN9218 write cycles. PIO writes can be performed using Chip Select (nCS)
or Write Enable (nWR). Either or both of these control signals must go high between cycles for the
period specified.
PIO Writes are valid for 16- and 32-bit access. Timing for 16-bit and 32-bit PIO write cycles are
identical with the exception that D[31:16] are ignored during a 16-bit write.
A[7:1]
nCS, nRD
Data Bus
Figure 6.5 PIO Write Cycle Timing
Note: The “Data Bus” width is 32 bits with optional support for 16-bit bus widths.
Table 6.7 PIO Write Cycle Timing
SYMBOL
DESCRIPTION
MIN
TYP
MAX
UNITS
tcycle
tcsl
Write Cycle Time
45
32
13
0
ns
ns
ns
ns
ns
ns
nCS, nWR Assertion Time
nCS, nWR Deassertion Time
Address Setup to nCS, nWR Assertion
Address Hold Time
tcsh
tasu
tah
0
tdsu
Data Setup to nCS, nWR Deassertion
7
Revision 1.5 (07-18-06)
120
SMSC LAN9218
DATASHEET
