High Performance Two Port 10/100 Managed Ethernet Switch with 32-Bit Non-PCI CPU Interface
Datasheet
8.4.3
Special Restrictions on Back-to-Back Read Cycles
There are also restrictions on specific back-to-back host read operations. These restrictions concern
reading specific registers after reading a resource that has side effects. In many cases there is a delay
between reading the LAN9312, and the subsequent indication of the expected change in the control
and status register values.
In order to prevent the host from reading stale data on back-to-back reads, minimum wait periods have
been established. These periods are specified in Table 8.2. The host processor is required to wait the
specified period of time between read operations of specific combinations of resources. The wait period
is dependant upon the combination of registers being read.
Performing “dummy” reads of the Byte Order Test Register (BYTE_TEST) register is a convenient way
to guarantee that the minimum wait time restriction is met. Table 8.2 below also shows the number of
dummy reads that are required for back-to-back read operations. The number of BYTE_TEST reads
in this table is based on the minimum timing for Tcyc (45ns). For microprocessors with slower busses
the number of reads may be reduced as long as the total time is equal to, or greater than the time
specified in the table. Dummy reads of the BYTE_TEST register are not required as long as the
minimum time period is met.
Table 8.2 Read After Read Timing Rules
OR PERFORM THIS MANY
WAIT FOR THIS MANY
READS OF BYTE_TEST…
(ASSUMING TCYC OF 45NS)
AFTER READING...
NANOSECONDS...
BEFORE READING...
RX Data FIFO
RX Status FIFO
TX Status FIFO
RX_DROP
135
135
135
180
45
3
3
3
4
1
RX_FIFO_INF
RX_FIFO_INF
TX_FIFO_INF
RX_DROP
SWITCH_CSR_DATA
SWITCH_CSR_CMD
Note 8.1
VPHY_AN_EXP
45
1
VPHY_AN_EXP
Note 8.1 This timing applies only to the auto-increment and auto-decrement modes of Switch Fabric
CSR register access.
SMSC LAN9312
105
Revision 1.2 (04-08-08)
