Non-PCI Single-Chip Full Duplex Ethernet Controller with Magic Packet
5. LED drivers for collision, transmission, reception, and jabber.
9.10 10Base-T
The 10BASE-T interface conforms to the twisted pair MAU addendum to the 802.3 specification. On the
transmission side, it converts the NRZ data from the controller to Manchester data and provides the
appropriate signal level for driving the media. Signal are predistorted before transmission to minimize ISI.
The collision detection circuitry monitors the simultaneous occurrence of received signals and transmitted
data on the media. During transmission, data is automatically looped back to the receiver except during
collision periods, in which case the input to the receiver is network data. During collisions, should the
receive input go idle prior to the transmitter going idle, input to the receiver switches back to the transmitter
within nine bit times. Following transmission, the transmitter performs a SQE test. This test exercises the
collision detection circuitry within the 10BASE-T interface.
The receiver monitors the media at all times. It recovers the clock and data and passes it along to the
controller. In the absence of any receive activity, the transmitter is looped back to the receiver. In addition,
the receiver performs automatic polarity correction. The 10BASE-T interface performs link integrity tests
per section 14.2.1.7 of 802.3, using the following values:
1. Link_loss_timer: 64 ms
2. Link_test_min_timer: 4 ms
3. Link_count: 2
4. Link_test_max_timer: 64 ms
The state of the link is reflected in the EPHSR.
9.11 AUI
The LAN91C96 also provides a standard six wire AUI interface to a coax transceiver.
9.12 Physical Interface
The internal physical interface (PHY) consists of an encoder/decoder (ENDEC) and an internal 10BASE-T
transceiver. The ENDEC also provides a standard 6-pin AUI interface to an external coax transceiver for
10BASE-2 and 10BASE-5 applications. The internal signals between MAC and the PHY can be routed to
pins by asserting the nXENDEC pin low. This feature allows the interface to an external ENDEC and
transceiver. The PHY functions can be divided into transmit and receive functions.
9.13 Transmit Functions
9.13.1 Manchester Encoding
The PHY encodes the transmit data received from the MAC. The encoded data is directed internally to the
selected output driver for transmission over the twisted-pair network or the AUI cable. Data transmission
and encoding is initiated by the Transmit Enable input, TXE, going low.
Rev. 09/10/2004
Page 86
