Small Footprint MII/RMII 10/100 Ethernet Transceiver for Automotive Applications
Datasheet
3.8.9.3
Connector Loopback
The device maintains reliable transmission over very short cables and can be tested in a connector
loopback as shown in Figure 3.9. An RJ45 loopback cable can be used to route the transmit signals
from the output of the transformer back to the receiver inputs. The loopback works at both 10 and
100 Mbps.
1
2
TXD
RXD
TX
RX
10/100
Ethernet
MAC
3
4
5
6
7
8
XFMR
Digital
Analog
RJ45 Loopback Cable.
Created by connecting pin 1 to pin 3
and connecting pin 2 to pin 6.
SMSC
Ethernet Transceiver
Figure 3.9 Connector Loopback Block Diagram
Revision 1.1 (05-26-10)
46
SMSC LAN88710AM/LAN88710BM
DATASHEET
