±15kV ESD Protected MII/RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support and flexPWR® Technology in a Small Footprint
Datasheet
Includes 25MHz Crystal for Internal PHY Reference; RX_CLK is Supplied to the 40-Pin Connector
Supports user configuration options including PHY address selection
Integrated 3.3V Regulator
APPLICATIONS
The EVB8700 Evaluation board simplifies the process of testing and evaluating an Ethernet
Connection in your application. The LAN8700 device is installed on the EVB board and all associated
circuitry is included, along with all configuration options.
The Benefits of adding an external MII interface are:
Easier system and software development
Verify MAC to PHY interface
Support testing of FPGA implementations of MAC
Assist interoperability test of various networks
Verify MII compliance
Verify performance of HP AutoMDIX feature
Verify Variable IO compliance
SMSC LAN8700/LAN8700i
Revision 2.3 (04-12-11)
DATA7S7HEET
SMSC [ SMSC CORPORATION ]
