Magnetics Selection
For a list of magnetics selected to operate with the SMSC LAN8700, please refer to the Application
note “AN 8-13 Suggested Magnetics”.
http://www.smsc.com/main/appnotes.html#Ethernet%20Products
Application Notes
Application examples are given in pdf format on the SMSC LAN8700 web site. The link to the web site
is shown below.
http://www.smsc.com/main/catalog/lan8700.html
Please check the web site periodically for the latest updates.
8.4
Reference Designs
The LAN8700 Reference designs are available on the SMSC LAN8700 web site link below.
http://www.smsc.com/main/catalog/lan8700.html
The reference designs are available in four variations:
a. MII with +3.3V IO
b. RMII with +3.3V IO
c. MII with +1.8V IO
d. RMII with +1.8V IO.
8.5
Evaluation board
The EVB-LAN8700 is a a PHY Evaluation Board (EVB) that interfaces a MAC controller to the SMSC
LAN8700 Ethernet PHY through an MII connector, and out to an RJ-45 Ethernet Jack through industrial
temperature magnetics for 10/100 connectivity.
Schematics(*.pdf and *.dsn), BOM (bill of materials), user guide, gerber files and Layout board file are
all available on the EVB web site link below.
http://www.smsc.com/main/catalog/evblan8700.html
The EVB-LAN8700 is designed to plug into a user's test system using a 40 pin Media Independent
Interface (MII) connector. The MII connector is an AMP 40 pin Right Angle through hole MII connector,
PN AMP- 174218-2. The mating connector is PN AMP 174217-2.
FEATURES:
Industrial temperature PHY and Magnetics
8 pin SOIC for user configurable Magnetics
On board LED indicators for Speed 100
Full Duplex
RJ-45 Connector LEDs for Link and Activity
Interfaces Through 40-pin Connector as Defined in the MII Specification
Powered by 5.0V from the 40-Pin MII Connector
Standard RJ45 Connector with LED indicators for Link and Activity
Includes Probe Points on All MII Data and Control Signals for Troubleshooting
