±15kV ESD Protected MII/RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support and flexPWR® Technology in a Small Footprint
Datasheet
Note: For VDDIO operation below +2.5V, SMSC recommends designs add external strapping
resistors in addition the internal strapping resistors to ensure proper strapped operation.
Table 7.12 100Base-TX Transceiver Characteristics
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Peak Differential Output Voltage High
Peak Differential Output Voltage Low
Signal Amplitude Symmetry
Signal Rise & Fall Time
Rise & Fall Time Symmetry
Duty Cycle Distortion
V
950
-950
98
3.0
-
-
-
1050
-1050
102
5.0
mVpk
mVpk
%
Note 7.4
Note 7.4
Note 7.4
Note 7.4
Note 7.4
Note 7.5
PPH
V
PPL
V
-
SS
RF
T
-
nS
T
-
0.5
nS
RFS
D
35
-
50
-
65
%
CD
OS
Overshoot & Undershoot
Jitter
V
5
%
1.4
nS
Note 7.6
Note 7.4 Measured at the line side of the transformer, line replaced by 100Ω (± 1%) resistor.
Note 7.5 Offset from 16 nS pulse width at 50% of pulse peak
Note 7.6 Measured differentially.
Table 7.13 10BASE-T Transceiver Characteristics
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
NOTES
Transmitter Peak Differential Output Voltage
Receiver Differential Squelch Threshold
V
2.2
2.5
2.8
V
Note 7.7
OUT
V
300
420
585
mV
DS
Note 7.7 Min/max voltages guaranteed as measured with 100Ω resistive load.
Revision 2.3 (04-12-11)
SMSC LAN8700/LAN8700i
DATA7S4HEET
