ST7781

14. 8 - Color Display Mode

The ST7781 has a function to display in 8 colors. In this display mode, only V0 and V63 are used and power supplies to

other grayscales are turned off to reduce power consumption. In 8-color display mode, the γ-adjustment registers

KP5-0[2:0], RP1-0[2:0], VRP0 [3:0], KN5-0[2:0], RN1-0[2:0], VRN1 [4:0], VRN0 [3:0], are disabled and the power supplies

to V1 to V62 are halted. The ST7781 does not require DRAM data rewrite for 8-color display by writing the MSB to the rest

in each dot data to display in 8 colors.

Fig. 14.1 8-Color Display Mode

Ver. 1.7
