ST7669V
9.1.34 COLMOD: Interface Pixel Format (3AH)
A0
0
RD
1
WR
0
D7
0
D6
0
D5
1
D4
1
D3
1
D2
0
D1
1
D0
0
HEX
3AH
-
Command
1st parameter
1
1
0
-
-
-
-
-
D2
D1
D0
NOTE: “-“ Don’t care
Description
This command is used to define the format of RGB picture data, which is transferred via the MCU
Interface. The formats are shown in the table:
Interface Format
Not Defined
D2
0
D1
0
D0
0
Not Defined
0
0
1
8 Bit/Pixel
0
1
0
12 Bit/Pixel(Type A)
Not Defined
0
1
1
1
0
0
16 Bit/Pixel
1
0
1
18 Bit/Pixel
1
1
0
Not Defined
1
1
1
Note: In 8 bit/pixel or 16 bit/pixel mode, the LUT is applied to transfer data into the Frame Memory.
Restriction
Register
Availability
Status
Availability
Yes
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Power On Sequence
S/W Reset
Default Value
06h (18Bit/Pixel)
No Change
H/W Reset
06h (18Bit/Pixel)
Ver 1.3
128/208
6/4/2008
SITRONIX [ SITRONIX TECHNOLOGY CO., LTD. ]
