ST7669V
9.1.37 RDID3: Read ID3 (DCH)
A0
0
RD
1
WR
0
D7
1
D6
1
D5
0
D4
1
D3
1
D2
1
D1
0
D0
0
HEX
Command
1st parameter
2nd parameter
DCH
1
0
1
-
-
-
-
-
-
-
-
-
-
1
0
1
ID37 ID36 ID35 ID34 ID33 ID32 ID31 ID30
NOTE: “-“ Don’t care
Description This read byte returns 8-bit LCD module/driver ID.
D7-D0 (ID37 to ID30): LCD module/driver ID.
NOTE: See command RDDID (04h), 4th parameter.
Restriction
Register
Availability
Status
Availability
Yes
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Power On Sequence
S/W Reset
Default Value
TBD
TBD
TBD
H/W Reset
Flow Chart
Ver 1.3
132/208
6/4/2008
