ST7669V
Restriction
Since the value of the Vertical Scrolling Start Address is absolute (with reference to the Frame
Memory), it must not enter the fixed area (defined by Vertical Scrolling Definition (33h)-otherwise
undesirable image will be displayed on the Panel.
SSA [7:0] is based on line unit.
SSA [7:0] = 00h, 01h, 02h, 03h, … , A1h
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
No
No
Yes
Default
Status
Power On Sequence
S/W Reset
Default Value
00h
00h
00h
H/W Reset
Flow Chart
See Vertical Scrolling Definition (33h) description.
Ver 1.3
124/208
6/4/2008
