ST7669V
9.1.35 RDID1: Read ID1 (DAH)
A0
0
RD
1
WR
0
D7
1
D6
1
D5
0
D4
1
D3
1
D2
0
D1
1
D0
0
HEX
Command
1st parameter
2nd parameter
DAH
1
0
1
-
-
-
-
-
-
-
-
-
-
1
0
1
ID17 ID16 ID15 ID14 ID13 ID12 ID11 ID10
NOTE: “-“ Don’t care
Description
This read byte returns 8-bit LCD module’s manufacturer ID
D7-D0 (ID17 to ID10): LCD module’s manufacturer ID.
NOTE: See command RDDID (04h), 2nd parameter.
Restriction
Register
Availability
Status
Availability
Yes
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Power On Sequence
S/W Reset
Default Value
TBD
TBD
TBD
H/W Reset
Flow Chart
Ver 1.3
130/208
6/4/2008
