ST7565S
Power Controller Set
This command sets the power supply circuit functions. See the function explanation in “The Power Supply Circuit,” for details
E
R/W
A0 /RD /WR
D7 D6 D5 D4 D3 D2 D1 D0
Selected Mode
Booster circuit: OFF
Booster circuit: ON
0
0
1
0
1
0
1
0
1
Voltage regulator circuit: OFF
Voltage regulator circuit: ON
0
1
0
0
1
Voltage follower circuit: OFF
Voltage follower circuit: ON
V5 Voltage Regulator Internal Resistor Ratio Set
This command sets the V5 voltage regulator internal resistor ratio. For details, see the function explanation is “The Voltage
Regulator circuit " and Table 11 .
E
R/W
A0 /RD /WR
D7 D6 D5 D4 D3 D2 D1 D0
Rb/Ra Ratio
0
0
1
0
0
0
0
0
0
0
1
1
1
0
1
0
Small
0
1
0
1
1
1
1
Large
The Electronic Volume (Double Byte Command)
This command makes it possible to adjust the brightness of the liquid crystal display by controlling the LCD drive voltage V5
through the output from the voltage regulator circuits of the internal liquid crystal power supply. This command is a two byte
command used as a pair with the electronic volume mode set command and the electronic volume register set command, and
both commands must be issued one after the other.
The Electronic Volume Mode Set
When this command is input, the electronic volume register set command becomes enabled. Once the electronic volume mode
has been set, no other command except for the electronic volume register command can be used. Once the electronic volume
register set command has been used to set data into the register, then the electronic volume mode is released.
E
R/W
A0 /RD /WR
D7 D6 D5 D4 D3 D2 D1 D0
0
1
0
1
0
0
0
0
0
0
1
Ver 0.6c
47/72
2009/09/07
