EFM32G Data Sheet
TQFP64 Package Specifications
8.2 TQFP64 PCB Layout
a
p8
p7
p6
p1
b
c
e
p2
p5
p3
p4
d
Figure 8.2. TQFP64 PCB Land Pattern
Table 8.2. TQFP64 PCB Land Pattern Dimensions (Dimensions in mm)
Symbol
Dim. (mm)
1.60
Symbol
P1
Pin Number
Symbol
P6
Pin Number
a
b
c
d
e
1
48
49
64
0.30
P2
16
17
32
33
P7
0.50
P3
P8
11.50
11.50
P4
P5
a
b
c
e
d
Figure 8.3. TQFP64 PCB Solder Mask
Table 8.3. TQFP64 PCB Solder Mask Dimensions (Dimensions in mm)
Symbol
Dim. (mm)
1.72
a
b
c
d
e
0.42
0.50
11.50
11.50
