LC89057W-VF4A-E
______
CCB address: 0xE8; Command address: 8; Demodulation function: INT output contents setting
DI7
DI6
DI5
DI4
DI3
DI2
DI1
DI0
1
0
0
0
0
0
CAU
CAL
DI15
DI14
DI13
DI12
DI11
DI10
DI9
DI8
EMPF
SLIPO
PCRNW
UNPCM
CSRNW
FSCHG
INDET
ERROR
ERROR
INDET
FSCHG
CSRNW
UNPCM
PCRNW
SLIPO
RERR signal output setting
0: Don't output (initial value)
1: Output RERR pin status change
Input data detection output setting
0: Don't output (initial value)
1: Output input data pin status change
Setting of updated flag output of PLL lock frequency calculation result
0: Don't output (initial value)
1: Output updated flag of PLL lock frequency calculation result
Output setting for updated flag of first 48-bit channel status data
0: Don't output (initial value)
1: Output update flag of first 48-bit channel status data
Output setting for change flag of non-PCM data detection
0: Don't output (initial value)
____________
1: Output AUDIO pin status change
Output setting for updated flag of burst preamble Pc
0: Don't output (initial value)
1: Output updated flag of burst preamble Pc
Output setting of slip signal during slave operation
0: Don't output (initial value)
1: Output duplicate reading and a detection flag for missing of data output
EMPF
Output setting of emphasis detection flag
0: Don't output (initial value)
1: Output emphasis detection flag
•
•
The channel status update flag compares the first 48 bits of data of the previous block with those of the current block.
If these data are identical, it outputs a flag, considering the data has been updated.
The burst preamble Pc update flag also compares the 16 bits of data of the previous block with those of the current
data. If they are identical, an update flag is output.
No.7202-46/59
