LC75852 参数 Datasheet PDF下载

型号：	LC75852
PDF下载：	下载PDF文件查看货源
内容描述：	带有片上按键输入功能异步硅栅1/2占空比LCD驱动器 [Asynchronous Silicon Gate 1/2 Duty LCD Driver with On-Chip Key Input Function]
分类和应用：	驱动器栅
文件页数/大小：	16 页 / 339 K
品牌：	SANYO [ SANYO SEMICON DEVICE ]

LC75852E, 75852W

Sample Application Circuit

Note: * Since DO is an open-drain output, a pull-up resistor is required. Select a value (between 1 and 10 kΩ) that is appropriate for the capacitance of the

external wiring so that the waveforms are not distorted.

Notes on Controller Display Data Transfer

The LC75852 transfers the display data (D1 to D90) in two operations. To assure visual display quality, all the display

data should be sent within a 30 ms or shorter period.

No. 4828-13/16
