Figure 3 Combining with Software
• Outputting the unlocked state data in the serial data
At the point of data output 1 in figure 3, the unlocked state data will indicate the unlocked state, since the VCO
frequency is not stable (locked) yet. In cases such as this, the application should wait at least one whole period and then
check again whether or not the frequency has stabilized with the data output 2 operation in the figure. Applications can
implement even more reliable recognition of the locked state by performing several more checks of the state and
requiring that the locked state be detected sequentially.
<Flowchart for Lock Detection>
Divisor N changed (data input)
Wait at least 2 reference frequency periods.
Data output (1)
Valid output data is acquired by using an interval of at
least one reference frequency period.
Data output (2)
*: Even more reliable recognition of the locked state
can be achieved by performing several checks of the
state and requiring that the locked state be detected
sequentially.
Locked state check
NO
YES
A10180
• Directly outputting the unlocked state to the DO pin
Since the unlocked state (high level when locked, low when unlocked) is output from the DO pin, applications can
check for the locked state by waiting at least two reference frequency periods after changing the divisor N. However, in
this case also, even more reliable recognition of the locked state can be achieved by performing several checks of the
state and requiring that the locked state be detected sequentially.
