S3C4510B
ETHERNET CONTROLLER
Carrier Sense== On
yse
Carrier sense = On,
after detection SFD,
store byte-stream in in FISO
no
Discard the Frame
Report Error Status
Recognize Address?
Move the byte stream in
the FIFO to the receive
buffer memory
Frame too short ?
Frame too long?
Valid FCS ?
Interrput CPU for
Handing the Frame
Check ethertype or length field
Disassemble Frame
MAC Drive Software
(Software jobs for typical LAN cards)
Signal to Upper Layer
Figure 7-24. CSMA/CD Receive Operation
7-57
