K9F5608U0B-VCB0,VIB0,FCB0,FIB0
K9F5608Q0B-DCB0,DIB0,HCB0,HIB0
K9F5608U0B-YCB0,YIB0,PCB0,PIB0
K9F5608U0B-DCB0,DIB0,HCB0,HIB0
K9F5616Q0B-DCB0,DIB0,HCB0,HIB0
K9F5616U0B-YCB0,YIB0,PCB0,PIB0
K9F5616U0B-DCB0,DIB0,HCB0,HIB0
FLASH MEMORY
Pointer Operation of K9F5616X0B(X16)
Samsung NAND Flash has two address pointer commands as a substitute for the most significant column address. ’00h’ command
sets the pointer to ’A’ area(0~255word), and ’50h’ command sets the pointer to ’B’ area(256~263word). With these commands, the
starting column address can be set to any of a whole page(0~263word). ’00h’ or ’50h’ is sustained until another address pointer com-
mand is inputted. To program data starting from ’A’ or ’B’ area, ’00h’ or ’50h’ command must be inputted before ’80h’ command is
written. A complete read operation prior to ’80h’ command is not necessary.
"A" area
"B" area
(00h plane)
(50h plane)
256 Word
8 Word
Table 3. Destination of the pointer
Command
Pointer position
Area
00h
50h
0 ~ 255 word
256 ~ 263 word
main array(A)
spare array(B)
"A"
"B"
Internal
Page Register
Pointer select
command
(00h, 50h)
Pointer
Figure 5. Block Diagram of Pointer Operation
(1) Command input sequence for programming ’A’ area
The address pointer is set to ’A’ area(0~255), and sustained
Address / Data input
Address / Data input
00h
80h
10h
00h
80h
10h
’A’,’B’ area can be programmed.
’00h’ command can be omitted.
It depends on how many data are inputted.
(2) Command input sequence for programming ’B’ area
The address pointer is set to ’B’ area(256~263), and sustained
Address / Data input
Address / Data input
80h 10h
50h
80h
10h
50h
Only ’B’ area can be programmed.
’50h’ command can be omitted.
18
