BD7xxL5FP-C
●Application Examples
・Applying positive surge to the VCC pin
If the possibility exists that surges higher than 50V will be applied to the VCC pin, a zenar diode should be placed
between the VCC pin and GND pin as shown in the figure below.
TO252-3
・Applying negative surge to the VCC pin
If the possibility exists that negative surges lower than the GND are applied to the VCC pin, a Shottky diode should be
place between the VCC pin and GND pin as shown in the figure below.
TO252-3
・Implementing a protection diode
If the possibility exists that a large inductive load is connected to the output pin resulting in back-EMF at time of startup
and shutdown, a protection diode should be placed as shown in the figure below.
VOUT
●I/O equivalence circuits
○Input terminal
○Output terminal *inside of () shows 5V
