UndefToOCIF
If the UNDEFtoOCIF bit is logic 1, all OAM cells with an undefined OAM Type or Function
Type value are copied to the Output Cell Interface at flow end-points. Regardless of the state
of this bit, all OAM cells with an undefined OAM Type or Function Type value are output to
the Output Cell Interface if the S/UNI-ATLAS-3200 is not an end point for that connection.
UNDEFtoUP
If the UNDEFtoUP bit is logic 1, all OAM cells with an undefined OAM Type or Function
Type value are copied to the Microprocessor Cell Interface at flow end-points. Regardless of
the state of this bit, all OAM cells with an undefined OAM Type or Function Type value are
output to the Output Cell Interface if the S/UNI-ATLAS-3200 is not an end point for that
connection.
UNDEFtoBCIF
If the UNDEFtoBCIF bit is logic 1, all OAM cells with an undefined OAM Type or Function
Type value are copied to the Backwards Cell Interface at flow end-points. Regardless of the
state of this bit, all OAM cells with an undefined OAM Type or Function Type value are
output to the Output Cell Interface if the S/UNI-ATLAS-3200 is not an end point for that
connection.
SYSMANtoOCIF
If the SYSMANtoOCIF bit is logic 1, all System Management cells are routed to the Output
Cell Interface. If the SYSMANtoOCIF is logic 0, then at flow end-points, all System
Management cells are dropped. Regardless of the state of this bit, all System Management
cells are routed to the Output Cell Interface if the S/UNI-ATLAS-3200 is not a flow end-point
for that connection.
SYSMANtoUP
If this bit is logic 1, all System Management OAM cells are copied to the Microprocessor
Cell Interface at flow end-points. Regardless of the state of this bit, all System Management
OAM cells are output to the Output Cell Interface if the S/UNI-ATLAS-3200 is not an end-
point for that connection.
SYSMANtoBCIF
If this bit is logic 1, all System Management OAM cells are copied to the Backwards Cell
Interface at flow end-points. Regardless of the state of this bit, all System Management
OAM cells are output to the Output Cell Interface if the S/UNI-ATLAS-3200 is not an end-
point for that connection.
