Register 0x048: ICLK Delay Locked Loop Register 1
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x040 for a complete description.
Register 0x049: ICLK DLL Register 2
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x041 for a complete description.
Register 0x04A: ICLK DLL Register 3
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x042 for a complete description.
Register 0x04B: ICLK DLL Register 4
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x043 for a complete description.
Register 0x050: OCLK Delay Locked Loop Register 1
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x040 for a complete description.
Register 0x051: OCLK DLL Register 2
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x041 for a complete description.
Register 0x052: OCLK DLL Register 3
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x042 for a complete description.
Register 0x053: OCLK DLL Register 4
The Operation of this register is identical to the SYSCLK Delay Locked Loop. Refer to
register 0x043 for a complete description.
