10.2.1 Framer
The Framer Block determines the in-frame/out-of-frame status of the receive stream. While in-
frame, the framing bytes (A1, A2) in each frame are compared against the expected pattern.
Out-of-frame is declared when four consecutive frames containing one or more framing pattern
errors have been received.
While out of frame, the CRSI block monitors the bit-serial STS-3c/STM-1 data stream for an
occurrence of the framing pattern (A1, A2). The CRSI informs the RSOP Framer block when
three A1 bytes followed by three A2 bytes has been detected to reinitializes the frame byte
counter to the new alignment. The Framer block declares frame alignment on the next
SONET/SDH frame when either all A1 and A2 bytes are seen error-free or when only the first
A1 byte and the first four bits of the last A2 byte are seen error-free depending upon the selected
framing algorithm.
Once in frame, the Framer block monitors the framing pattern sequence and declares out of
frame (OOF) when one or more bits errors in each framing pattern are detected for four
consecutive frames. Again, depending upon the algorithm either all framing bytes are examined
for bit errors each frame, or only the first A1 byte and the first four bits of the last A2 byte are
examined for bit errors each frame.
10.2.2 Descramble
The Descramble Block utilizes a frame synchronous descrambler to process the receive stream.
7
6
The generating polynomial is x + x + 1 and the sequence length is 127. Details of the
descrambling operation are provided in the references. Note that the framing bytes (A1 and A2)
and the trace/growth bytes (J0/Z0) are not descrambled. A register bit is provided to disable the
descrambling operation.
10.2.3 Data Link Extract
The Data Link Extract Block extracts the section data communication channel (bytes D1, D2,
and D3) from an STS-3c/STM-1 stream. The extracted bytes are serialized and are output on
the associated RDCC signal at a nominal 192 kbit/s rate. Timing for downstream processing of
the data communication channel is provided by the RDCLK signal that is also output by the
Data Link Extract Block. RDCLK is derived from a 216 kHz clock that is gapped to yield an
average frequency of 192 kHz. RDCC is updated with timing aligned to RDCLK.
