S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Pin Name
Type
Pin
No.
Function
AVS[0]
AVS[1]
AVS[2]
AVS[3]
AVS[4]
AVS[5]
AVS[6]
AVS[7]
AVS[8]
Analog
Ground
N1
P4
P2
R4
R3
U2
U3
V5
W2
The analog ground (AVS[8:0]) pins for the analog core. The
AVS pins should be connected to the analog ground of the
analog power supply.
Please see the Operation section for detailed information.
VDDI
Digital
Power
AB5
AD27
AE5
AF5
AG12
AG13
AG17
AG18
AG19
AG9
E13
E17
E18
E20
E25
E7
The core digital power (VDDI) pins should be connected to a
well-decoupled +2.5 V digital power supply.
E9
G5
H27
K5
M5
N27
W27
