S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x0AC, 0x1AC, 0x2AC, 0x3AC, 0x4AC, 0x5AC, 0x6AC, 0x7AC:
RXFP Receive Frame Count LSB
Bit
Type
R
R
R
R
R
R
R
R
Function
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
RFRAME[7]
RFRAME[6]
RFRAME[5]
RFRAME[4]
RFRAME[3]
RFRAME[2]
RFRAME[1]
RFRAME[0]
X
X
X
X
X
X
X
X
Register 0x0AD, 0x1AD, 0x2AD, 0x3AD, 0x4AD, 0x5AD, 0x6AD, 0x7AD:
RXFP Receive Frame Count
Bit
Type
R
R
R
R
R
R
R
R
Function
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
RFRAME[15]
RFRAME[14]
RFRAME[13]
RFRAME[12]
RFRAME[11]
RFRAME[10]
RFRAME[9]
RFRAME[8]
X
X
X
X
X
X
X
X
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
257
