S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Offset
03F
040
041
042
043
044
045
046
047
048
049
04A
04B
04C
04D
04E
04F
050
051
052
053
054
055
056
057
058
059
05A
05B
05C
05D
05E
05F
060
061
062
063
064
065
066
Register Description
RPOP Reserved
TPOP Control/Diagnostic
TPOP Pointer Control
TPOP Reserved
TPOP Current Pointer LSB
TPOP Current Pointer MSB
TPOP Arbitrary Pointer LSB
TPOP Arbitrary Pointer MSB
TPOP Path Trace
TPOP Path Signal Label
TPOP Path Status
TPOP Reserved
TPOP Reserved
TPOP Reserved
TPOP Reserved
TPOP Concatenation LSB
TPOP Concatenation MSB
SPTB Control
SPTB Path Trace Identifier Status
SPTB Indirect Address Register
SPTB Indirect Data Register
SPTB Expected Path Signal Label
SPTB Path Signal Label Status
SPTB Indirect Access Trigger Register
SPTB Reserved
DCRU Configuration
DCRU Reserved
DCRU Reset
DCRU Reserved
CRSI Configuration
CRSI Status
CRSI Reserved
CRSI Reserved
RXCP Configuration 1
RXCP Configuration 2
RXCP FIFO/UTOPIA Control and Configuration
RXCP Interrupt Enable and Counter Status
RXCP Status/Interrupt Status
RXCP LCD Count Threshold LSB
RXCP LCD Count Threshold MSB
