Sample Configuration Procedure
The sequence executed to set up and initialize a PEX 8532 switch is as follows:
1. Ports and lanes, per port:
• Refer to Section 4.1.2.1, “Port Combinations,” for options
• PEX 8532 must be connected to PCI Express-compatible devices
• Strapping balls must be set to identify the selected port configuration
– For Station 0, refer to STRAP_STN0_PORTCFG[4:0]
– For Station 1, refer to STRAP_STN1_PORTCFG[4:0]
• Serial EEPROM overrides the Strapping ball selections
2. Select the upstream port – Set Strapping balls STRAP_UPSTRM_PORTSEL[3:0].
3. Software/serial EEPROM programs the following registers for the upstream port:
• Primary Bus Number – Identifies the upstream link (Bus Number register, offset 18h[7:0])
• Secondary Bus Number – Identifies the switch internal Virtual PCI Bus
(Bus Number register, offset 18h[15:8])
• Subordinate Bus Number – Must be the last (largest) Bus Number in the downstream
hierarchy of this upstream port (Bus Number register, offset 18h[23:16])
• Set the Command register Bus Master Enable and Memory Access Enable bits
(offset 04h[2:1], respectively)
• Base and Limit registers – Combines the memory of all downstream devices into one
large space, with the total size given by Limit - Base, and the Start address given by Base
• Base Address 0 and Base Address 1 registers (BAR0 and BAR1, offsets 10h and 14h,
respectively) (Base address for Memory-Mapped CSR access on the PEX 8532)
4. Software/serial EEPROM programs the following registers for the downstream ports:
• Primary Bus Number – All downstream port numbers are the Device Numbers
on the internal virtual PCI Bus (Bus Number register, offset [7:0])
• Secondary Bus Number – Identifies the port’s downstream link
(Bus Number register, offset [15:8])
• Subordinate Bus Number – Must be the last (largest) Bus Number in the downstream
hierarchy of each downstream port (Bus Number register, offset 18h[23:16])
• Set the Command register Bus Master Enable and Memory Access Enable bits
(offset 04h[2:1], respectively)
• Base and Limit registers – Combines the memory of all downstream devices into one
large space, with the total size given by Limit - Base, and the Start address given by Base
On the upstream port, the primary side is accessed by a Type 0 Configuration access. The downstream
ports are accessed with a Type 1 Configuration access on the primary side of the upstream port, with the
Bus Number of each transaction equal to the upstream port Secondary Bus Number (Virtual PCI Bus).
