TDA8944J
2 x 7 W stereo BTL audio amplifier
Philips Semiconductors
MGL958
0
handbook, halfpage
α
cs
(dB)
−20
−40
−60
−80
−100
2
3
4
5
10
10
10
10
10
f (Hz)
No bandpass filter applied.
Fig 12. Channel separation as function of frequency.
MGL956
0
handbook, full pagewidth
SVRR
(dB)
−20
−40
B
CH2
CH1
−60
A
−80
2
3
4
5
10
10
10
10
10
f (Hz)
VCC = 12 V; Rs = 0 Ω; Vripple = 707 mV (peak-to-peak); no bandpass filter applied.
Curves A: inputs short-circuited
Curves B: inputs short-circuited and connected to ground (asymmetrical application)
Fig 13. Supply voltage ripple rejection as function of frequency.
