TDA8944J
2 x 7 W stereo BTL audio amplifier
Philips Semiconductors
14.2 Thermal behaviour and heatsink calculation
The measured maximum thermal resistance of the IC package, Rth(j-mb) is 6.9 K/W.
A calculation for the heatsink can be made, with the following parameters:
Tamb(max) = 50 °C
VCC = 12 V and RL = 8 Ω
Tj(max) = 150 °C.
Rth(tot) is the total thermal resistance between the junction and the ambient
including the heatsink. In the heatsink calculations the value of Rth(mb-h) is ignored.
At VCC = 12 V and RL = 8 Ω the measured worstcase sine-wave dissipation is 8 W;
see Figure 11. For Tj(max) = 150 °C the temperature raise - caused by the power
dissipation - is: 150 – 50 = 100 °C.
P × Rth(tot) = 100 °C
Rth(tot) = 100/8 = 12.5 K/W
Rth(h-a) = Rth(tot) – Rth(j-mb) = 12.5 – 6.9 = 5.6 K/W.
The calculation above is for an application at worstcase (stereo) sine-wave output
signals. In practice music signals will be applied, which decreases the maximum
power dissipation to approximately half of the sine-wave power dissipation (see
Section 8.2.2). This allows for the use of a smaller heatsink:
P × Rth(tot) = 100 °C
Rth(tot) = 100/4 = 25 K/W
Rth(h-a) = Rth(tot) – Rth(j-mb) = 25 – 6.9 = 18.1 K/W.
To increase the lifetime of the IC, Tj(max) should be reduced to 125 °C. This requires a
heatsink of approximately 12 K/W for music signals.
15. Test information
15.1 Quality information
The General Quality Specification for Integrated Circuits, SNW-FQ-611D is
applicable.
15.2 Test conditions
Tamb = 25 °C; VCC = 12 V; f = 1 kHz; RL = 8 Ω; audio pass band 22 Hz to 22 kHz;
unless otherwise specified.
Remark: In the graphs as function of frequency no bandpass filter was applied; see
Figure 7, 12 and 13.
