ISP1160
Embedded USB Host Controller
Philips Semiconductors
16. Static characteristics
Table 68: Static characteristics; supply pins
VCC = 3.0 V to 3.6 V or 4.0 V to 5.5 V; VGND = 0 V; Tamb = −40 °C to +85 °C; typical values at Tamb = 25 °C; unless otherwise
specified.
Symbol
Parameter
Conditions
Min
Typ
Max
Unit
VCC = 5 V
VREG(3V3) internal regulator output
[1]
3.0
3.3
47
40
3.6
-
V
ICC
operating supply current
suspend supply current
-
-
mA
µA
ICC(susp
)
500
VCC = 3.3 V
ICC
operating supply current
suspend supply current
-
-
50
-
mA
[2]
ICC(susp
)
150
500
µA
[1] In the suspend mode, the minimum voltage is 2.7 V.
[2] For details on power consumption, refer to Philips Application Note AN10022 ISP1160x Low Power Consumption.
Table 69: Static characteristics: digital pins
VCC = 3.0 V to 3.6 V or 4.0 V to 5.5 V; VGND = 0 V; Tamb = −40 °C to +85 °C; unless otherwise specified.
Symbol
Input levels
VIL
Parameter
Conditions
Min
Typ
Max
Unit
LOW-level input voltage
HIGH-level input voltage
-
-
-
0.8
-
V
V
VIH
2.0
Schmitt trigger inputs
Vth(LH)
Vth(HL)
Vhys
positive-going threshold voltage
1.4
0.9
0.4
-
-
-
1.9
1.5
0.7
V
V
V
negative-going threshold voltage
hysteresis voltage
Output levels
VOL LOW-level output voltage
I
I
I
I
OL = 4 mA
OL = 20 µA
OH = 4 mA
OH = 20 µA
-
-
-
-
-
0.4
0.1
-
V
V
V
V
-
[1]
[2]
VOH
HIGH-level output voltage
2.4
V
REG(3V3) − 0.1
-
Leakage current
ILI
input leakage current
pin capacitance
−5
-
-
+5
µA
CIN
pin to GND
-
5
pF
Open-drain outputs
IOZ
OFF-state output current
−5
-
+5
µA
[1] Not applicable for open-drain outputs.
[2] The maximum and minimum values are applicable to transistor input only. The value will be different if internal pull-up or pull-down
resistors are used.
9397 750 11371
© Koninklijke Philips Electronics N.V. 2003. All rights reserved.
Product data
Rev. 04 — 04 July 2003
72 of 88
