2-input EXCLUSIVE-OR gate
74AHC1G86; 74AHCT1G86
AC CHARACTERISTICS
Type 74AHC1G86
Ground = 0 V; tr = tf ≤ 3.0 ns.
TEST CONDITIONS
Tamb (°C)
SYMBOL
PARAMETER
25
−40 to +85 −40 to +125 UNIT
CL
WAVEFORMS
(pF)
MIN. TYP. MAX. MIN. MAX. MIN. MAX.
VCC = 3.0 to 3.6 V; note 1
tPHL/tPLH
propagation delay see Figs 5 and 6 15
−
−
4.0
5.8
11.0 1.0
14.5 1.0
13.0 1.0
16.5 1.0
14.0 ns
18.5 ns
A and B to Y
50
VCC = 4.5 to 5.5 V; note 2
tPHL/tPLH
propagation delay see Figs 5 and 6 15
−
−
3.4
4.9
6.8
8.8
1.0
1.0
8.0
1.0
8.5
ns
A and B to Y
50
10.0 1.0
11.5 ns
Notes
1. Typical values are measured at VCC = 3.3 V.
2. Typical values are measured at VCC = 5.0 V.
74AHCT1G86
Ground = 0 V; tr = tf ≤ 3.0 ns.
TEST CONDITIONS
Tamb (°C)
SYMBOL
PARAMETER
25
−40 to +85 −40 to +125 UNIT
CL
WAVEFORMS
(pF)
MIN. TYP. MAX. MIN. MAX. MIN. MAX.
VCC = 4.5 to 5.5 V; note 1
tPHL/tPLH
propagation delay see Figs 5 and 6 15
−
−
3.5
5.0
6.9
7.9
1.0
1.0
8.0
9.0
1.0
1.0
9.0
ns
A and B to Y
50
10.5 ns
Note
1. Typical values are measured at VCC = 5 V.
