PFS122
8bit MTP MCU with 12-bit R-Type ADC
Case 3 : gpcs.5=1 & gpcs.4= 0
16 stages
VDD
8R
8R
8R
gpcs.4=0
gpcs.4=1
gpcs.5=1
R
R
R
R
gpcs.5=0
MUX
gpcs[3:0]
V internal R = (3/5) VDD ~ (1/5) VDD + (1/40) VDD
@ gpcs[3:0] = 1111 ~ gpcs[3:0] = 0000
1
5
(n+1)
40
V internal R
=
*
VDD +
*
VDD, n = gpcs[3:0] in decimal
Fig.7: Vinternal R hardware connection if gpcs.5=1 and gpcs.4=0
Case 4 : gpcs.5=1 & gpcs.4=1
16 stages
VDD
8R
8R
8R
gpcs.4=0
gpcs.4=1
gpcs.5=1
R
R
R
R
gpcs.5=0
MUX
gpcs[3:0]
V internal R = (1/2) VDD ~ (1/32) VDD
@ gpcs[3:0] = 1111 ~ gpcs[3:0] = 0000
(n+1)
V internal R
=
*
VDD, n = gpcs[3:0] in decimal
32
Fig.8: Vinternal R hardware connection if gpcs.5=1 and gpcs.4=1
