NXH25C120L2C2SG
ELECTRICAL CHARACTERISTICS (T = 25°C unless otherwise specified) (continued)
J
Parameter
Test Conditions
Symbol
Min
Typ
Max
Unit
RECTIFIER DIODE CHARACTERISTICS
Rectifier Reverse Leakage Current
Rectifier Forward Voltage
VR = 1600 V
I = 25 A, T = 25°C
IR
–
–
−
1
200
1.5
–
mA
V
F
V
F
J
I = 35 A, T = 150°C
–
1.1
F
J
Temperature under switching conditions
Tvj op
RthJC
−40
150
°C
Thermal Resistance − chip−to−case
THERMISTOR CHARACTERISTICS
Nominal resistance
Nominal resistance
Deviation of R25
–
0.86
–
°C/W
T = 25°C
R
–
–
5
493.3
–
–
–
5
–
–
–
–
kW
W
25
T = 100°C
R
100
nR/R
−5
–
%
Power dissipation
P
D
20
mW
mW/K
K
Power dissipation constant
B−value
–
1.4
B(25/50), tolerance 2%
B(25/100), tolerance 2%
–
3375
3433
B−value
–
K
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
