Memory Cassettes
An optional Memory Cassette can be used to store the user program, PLC setup, and other data in ROM so that vital data will not be lost
in the event of battery expiration or careless programming/monitoring operations.
If the PLC’s settings need to be changed to execute another process, the entire software setup and user program can be changed just by
exchanging the Memory Cassette and rebooting the PLC.
EEPROM:
Flash Memory:
EPROM:
CQM1-ME04K
CQM1-ME04R
CQM1-ME08K
CQM1-ME08R
CQM1H-ME16K
CQM1H-ME16R
CQM1-MP08K
CQM1-MP08R
J SPECIFICATIONS
Memory
Model
Specifications
EEPROM
CQM1-ME04K
CQM1-ME04R
CQM1-ME08K
CQM1-ME08R
CQM1-MP08K
CQM1-MP08R
CQM1H-ME16K
CQM1H-ME16R
4 kwords without clock
4 kwords with clock
8 kwords without clock
8 kwords with clock
EPROM
Without clock (see below)
With clock (see below)
16 kwords without clock
16 kwords with clock
Flash
Memory Cassette
Mounted from the front of the CPU and used to store and read the user’s program,
DM (read-only DM and PLC Setup), and expansion instruction information as one block.
It is possible to set the CPU so that data stored in the Memory Cassette (user’s
program, DM, expansion instruction information) is automatically sent to the CPU
(auto-boot) at startup. Transfer and comparison of data between the CPU and Memory
Cassette are possible using AR area control bits.
(EEPROM or flash memory)
EPROM Chips
The following EPROM chips (sold separately) are required for EPROM Memory Cassettes.
The chip is mounted in the I/O socket on the Memory Cassette.
Model
ROM version
Capacity
8 kwords
16 kwords
32 kwords
Access speed
150 ns
ROM-ID-B
ROM-JD-B
ROM-KD-B
27128 or equivalent
27256 or equivalent
27512 or equivalent
150 ns
150 ns
A--166
Programmable Controller CQM1H
