TDA8950
NXP Semiconductors
2 × 150 W class-D power amplifier
001aai703
0
α
cs
(dB)
−20
−40
−60
−80
−100
2
3
4
5
10
10
10
10
10
f (Hz)
VP = ±35 V, 2 × 4 Ω SE configuration
For OUT1 and OUT2 for both 1 W and 10 W.
Fig 18. Channel separation as a function of frequency, SE configuration with 2 × 4 Ω load
001aai704
0
α
cs
(dB)
−20
−40
−60
−80
−100
2
3
4
5
10
10
10
10
10
f (Hz)
VP = ±35 V, 2 × 6 Ω SE configuration
For OUT1 and OUT2 for both 1 W and 10 W.
Fig 19. Channel separation as a function of frequency, SE configuration with 2 × 6 Ω load
TDA8950_1
© NXP B.V. 2008. All rights reserved.
Preliminary data sheet
Rev. 01 — 9 September 2008
27 of 39
